BharatBenz 2523R 5175/HSD/BS-IV

1 ReviewsRate Now
This Model has expired
Price is for informational purposes only and the same may be subject to change. For details, please go through the T&C.
Home
BharatBenz Trucks
2523R
5175/HSD/BS-IV

Key Specifications of 2523R 5175/HSD/BS-IV

Power231.2
GVW25000 kg
Engine6372 cc
Fuel Tank380 Ltr
Payload17100 Kgs
Chassis TypeChassis with Cabin
Body OptionDeck Body

2523R 5175/HSD/BS-IV Specification & Features

Performance

Max Power231.2
Displacement (cc)6372 cc
Fuel Tank (Litres)380 Ltr
EngineDE175BS4
Emission NormsBS-IV
Max Torque850 Nm
Gradeability (%)24 %
Max Speed (km/h)80
Engine Cylinders6
Turning Radius (mm)9350

Dimension

Overall Length (mm)9867
Overall Width (mm)2490
Overall Height (mm)2960
Ground Clearance (mm)264
Wheelbase (mm)5175 mm
Axle Configuration6x2
Size (Cu. M)-
Length {mm (ft.)}7300 (24)
Width {mm (ft.)}NA
Height {mm (ft.)}NA

Transmission & Loading Capacity

TransmissionManual
Payload (Kgs)17100 Kgs
GVW / GCW (Kgs)25000 kg
Kerb Weight (Kgs)7290
Gear Box6-Speed
ClutchSingle dry plate,Hydraulic control with clutch booster,395 mm
Power SteeringYes

Features

SteeringPower Steering
A/COptional
Cruise ControlNo
Navigation SystemNo
Tiltable SteeringYes
Arm-restNo
Seat TypeStandard
Driver Information DisplayYes
Adjustable Driver SeatYes
Tubeless TyresNo
Seat BeltsYes
Hill HoldNo

Brakes & Suspension

BrakesPneumatic, Foot operated, Dual line with ABS
Front AxleIF6.6,Reverse elliot
Front SuspensionParabolic leaf spring with 2 hydraulic shock absorbers
Rear AxleIR440,Fully floating Hypoid gears
Rear SuspensionBalancer type semi elliptical leaf spring
ABSYes
Parking BrakesPneumatically operated hand control valve

Body Option & Cabin Type

Chassis TypeChassis with Cabin
Body OptionDeck Body
Cabin TypeSleeper Cabin
Tiltable CabinYes

Tyres

Rear Tyre10 R 20 - 16 PR
Front Tyre10 R 20 - 16 PR

Others

No. Of AxlesNA
Axle TypesNA
Body Brakes-
ChassisYes
Landing GearNA
Electricals24 V
Floor Type-
Body Material-
Canopy Length-
Water Tank Capacity (KL)-
Water Tank Type-
No. Of Valves-
Pump Type-
Bulker Type-
Bulker Discharge PipeNA
Bulker Air Inlet Pipe-
Bulker Equipments-
Bulker Electricals-
Floor Material-
Side Board Material-
Rear Board Material-
External/Interior Surface-
Refrigerating UnitNA
Temperature Range-
Battery(Volts)2 X 12 V,120 Ah
Fog LightsNo
