Performance
Engine
ZD30 Diesel Engine with DDTi (Double Overhead Camshaft , Common Rail, Direct Injecti on, Turbo Intercooled)
SLT4 & Numeral
Emission Norms
BS-IV
BS-IV
Displacement (cc)
2953
3455
Max Power
105 bhp
100.5bhp
Max Torque
284 Nm
296Nm
Transmission
Manual
Manual
Clutch
280 mm Dia, Single Dry Plate, Diaphragm Push Type
Single plate Diaphragm Type , Dia. 260mm
Gearbox
5-Speed
5-Speed
Fuel Tank (Litres)
90
90
Gradeability (%)
22
28
Turning Radius (mm)
6200
3200
Design & Build
Body Option
Fully Built
Deck Body
Chassis Type
Chassis with Cabin
Chassis with Cabin
Cabin Type
Day Cabin
Day Cabin
Front Tyre
8.25 x 16-16 PR
8.25" X 20" - 14/16 PR
Rear Tyre
8.25 x 16-16 PR
8.25" X 20" - 14/16 PR
Wheelbase (mm)
2670
3940
Overall Length (mm)
4920
5974
Overall Height (mm)
2850
2092
Ground Clearance (mm)
238
228
GVW / GCW (Kgs)
6020
5990
Kerb Weight (Kgs)
2760
4650
Payload (Kgs)
3620
4560
Comfort
Steering
Power Steering
Recirculation Ball Type
Cruise ControlNoNo
Navigation SystemYesNo
Driver Information DisplayYesNo
TelematicsYesNo
Adjustable Driver SeatYesNo
Tiltable SteeringYesNo
Arm-restYesNo
Seat TypeYesYes
Safety
Brakes
Hydraullic Brakes
Air Brake
Front Axle
आई सेक्शन रिवर्स इलियट
Forged "I" beam reverse Elliot type Axle
Front Suspension
Parabolic with Double Acti ng Shock Absorbers
Semi Elliptical type Multi leaf spring
Rear Axle
फुली फ्लोटिंग हाइफोटिंग एक्सल
Full floating banjo type Axle
Rear Suspension
Semi-ellipti c with Double Acti ng Shock Absorbers
Semi Elliptical type Multi leaf spring
ABSYesNo
Parking BrakesYesYes
Power SteeringYes
Optional
Fog LightsYesNo
Tubeless TyresYesNo
Seat BeltsYesYes
Hill HoldNoNo
Others
Size (Cu. M)NoNo
Length {mm (ft.)}
3160(10.36)
4260(14)
Width {mm (ft.)}
1960(6.43)
2080 (6.8)
Height {mm (ft.)}
1840(6.03)
1695 (5.6)
No. Of Axles
NA
No
Axle Types
NA
No
Body Brakes
Transmission mounted cable operated
Hydraulic Vacuum assisted
Chassis
NA
No
Landing Gear
NA
No
Electricals
75 V
No
Floor Type
NA
No
Body Material
NA
No
Canopy Length
NA
No
Water Tank Capacity (KL)
NA
No
Water Tank Type
NA
No
No. Of Valves
NA
No
Pump Type
NA
No
Bulker Type
NA
No
Bulker Discharge Pipe
NA
No
Bulker Air Inlet Pipe
NA
No
Bulker Equipments
NA
No
Bulker Electricals
NA
No
Floor Material
NA
No
Side Board Material
NA
No
Rear Board Material
NA
No
External/Interior Surface
NA
No
Refrigerating Unit
NA
No
Temperature Range
NA
No
